Solenoid Valve - 2 Way: 2/2 - ASCO Series 215

8215B080CSA 120/60,110/50

Type: Solenoid Valve

Body Material: Aluminum

Media Type: Air, Inert Gas;Fuel Gas

Valve Actuation: Solenoid - Direct Acting

Voltage: 110 AC;120 AC

Max Ops Pressure(PSI): 25

Function: 2 way - 2/2 Normally Closed

Pipe Size: 2

Catalog Number: 8215B080CSA 120/60,110/50

General Information

Operating Pressure RatingsPSI

Operating Air Pressure (Min-Max): -25

Operating Water Pressure (Min-Max) -

Operating Oil Pressure (Min-Max) -

Technical Information

Actuation Method: Solenoid - Direct Acting

Body Material: Aluminum

Coil Class: FT

Coil Number

099257-001-D

I&M Pressure Vessel

V_5996_R10.pdf

I&M Solenoid

V_5381_R9.pdf
V_6950_CH.pdf
V_6950_R8.pdf

Pipe or Port Size: 2

Max Ambient Temperature: 125.00 F

Min Ambient Temperature: 32.00 F

Max Fluid Temperature: 125.00 F

Min Fluid Temperature: 32.00 F

Model Available

EF8320G202 24/DC ; 8215G020; 8215B070CSA; 8215B050CSA; 8215B060CSA; 8215G030 ; 8215A040CSA; 8215G033; 8215C053; 8215A090CSA; 8215G030 ; 8215G010; EF8215G020; SC8215G020; 8215G080; EF8215G030; EF8215B050; EF8215B080; EF8215B070; 8215G020B; 8215G023; EF8215G030; 8215G020; EF8215B060; EF8215C053; EF8215G033; 8215G050 ; 8215G003 ; 8215G050; 8215G060,…
